Ritter R113 – 13 Spindle Manual Single Row Line Boring Machine


  • 13-Spindle Line Boring Machine
  • 3/4 HP Spindle Drive Motor, TEFC
  • 60″ Back Fence Assembly
  • (1) 13-Vertical Gear Driven Spindle Rows
  • 10mm Bored Collets
  • (7) Right Hand, (6) Left Hand
  • (2) Index Pins
  • 20″ X 48″ Work Table Surface
  • Wired 1-Phase 120 Volt, 60 Hz.
  • Manually Actuated Boring Cycle
  • Tooling Not Included
  • Crated Dimensions: 45″ X 80″ X 44″ and 508 Lbs
  • Designed and Manufactured in the USA


The starting point for our line boring machines, this unit is both affordable and built to last. No more using templates that wear out quickly and lose accuracy. This machine is easily adjustable for entry and exit points, and cleanly allows the user to repeat the drill hole pattern with centering pins on both the left and right hand side of the machine. The rear fence is adjustable for offset from the edge as well. If you’re looking for your first line bore drill, look no further. This machine will give you many years of service with little to no maintenance. This is a clear choice among professionals.


For current product availability and our most competitive price delivered, please contact us using the “Request A Quote” button below. Due to vendor restrictions, we cannot always advertise our highly competitive pricing online.
