NT ES636SE Edge Sander
- 3HP main motor; 3PH, 230V/460V Dual Voltage
- (3/8″) oscillating stroke
- Drive wheel: 7″ x 6-5/8″
- Easy elevation control through the manual worm gear
- Side table dimensions: (1) 10-1/2″ x 35-3/4″
- Side table tilt: 0° – 45°
- End table dimensions: (1) 13-3/4″ x 16-1/2″
- End table tilt: 0° – 45°
- Sanding belt size: 6″ x 109″ (Included)
- Sanding belt speed: 3,300 FPM
- Platen size: 6.5″ x 36″
- Dust ports: ( 2) 4″ requiring 500 CFM @ point of extraction
- Easy jig fences are standard for squaring accuracy and part stability
- Machine Dimensions: 64″ x 25″ x 39-1/2″
- Packaging Dimensions: 69″ x 31″ x 49″
- Net weight: 572 lbs
- Gross weight: 725 lbs
- (1) Toolbox
- Warranty is one-year parts
- All machines are tested stateside before shipment providing trouble-free start-up.
- Direct Drive = Motor to 7” x 6-5/8” Pulley
- Machine Hp. = 3 hp.
- Voltage/ Freq. = 230/460Volt 60Hz
- Phase = 3 Phase
- Amp Requirement = 9/4.5 Amps
- Elevation Sys. = (2) Post Jack Screw
- Elevation Style = Manual Wheel Adjustment
- Electronics = CE Approved Components
- Dual Voltage = 230/460 Volt
- Control Voltage = 24 Volt Control Voltage
- Pass-Line = 32”
- Max. Length = 36”
- Max. Thickness = 6”
- Sandpaper Size = 6” x 109”
- Platen Specs. = 6” x 36”
- 1st Belt Speed = 3300 FPM
- Oscillation Sty = Gear Box with Cam
- Oscillation Rte = 30 Cycles/Minute
- Oscillation Trv = 3/8”
- Tracking Style = Manual Adjustment
- Tension Style = Manual Adjustment
- Vertical Travel = 4” Table Travel
- Dust Collection = (2) 4” @ 900 CFM
- Emergency Stop = Push Button
- Guarding = High Visibility Guarding
- Fence Type = Jig Fence
- Tiltable = 45 Degrees
- Frame Const. = 1/4” Steel Construction
- End Table Dims. = 13-3/4” x 16-1/2”
- Worktable Dims. = 10-1/2” x 35-3/4”
- Table Const. = Steel
- Decible Rating = 72 dB
- Net Weight = 570 Lbs.
- Gross Weight = 722 Lbs.
- Machine Dims. = 64” x 25” x 39-1/2”
- Packaging Dims = 68” x 30” x 49-1/2”
