SCM minimax sc 4e Sliding Table Saw (1-phase or 3-phase)

SCM minimax sc 4e Sliding Table Saw (1-phase or 3-phase)

Price range: $10,475.00 through $10,975.00

You will be very hard pressed to find a slider this nicely equipped at this price point. This is SCM’s entry level 8.5′ slider and it comes well optioned while being made in Italy!

The Minimax sc 4e series represents a premier entry-level production solution designed for small cabinet shops and serious hobbyists who require industrial accuracy without a massive investment. This versatile circular saw features a robust, solid cast-iron saw unit with double trunnions and an independently adjustable scoring unit to ensure a perfect, tear-out-free cut every time. Offering a generous 51-inch rip capacity and a micro-adjustable rip fence, the machine provides the same high-level specifications found on more expensive models, including a large 1100 x 650 mm squaring frame for superior workpiece stability. Available with various anodized-aluminum sliding table strokes ranging up to 8.5 feet, the SC 4 Elite combines SCM’s proven engineering with a space-saving design to deliver professional-grade results and exceptional reliability in a class of its own.

Our brand new sliding table saw, the Elite series has proven itself in American cabinet shops for many years. This machine boasts a full 8.5’ stroke, and features normally found on much more expensive machines, for a fraction of the cost. See for yourself why the SC4 Elite 8.5 foot machine stands in a class of its own.

*Photos may include optional equipment.

Advertised Price Configurations:

SC 4E -1ph, 4.8 HP, 8.5′ slider, 12″ tilting blade, 50″ rip capacity, belt driven scoring blade, DADO capability, miter gauge, additional table, 5/8″ Arbor

SC 4E – 3ph 9,985 3ph, 8 HP, 8.5′ slider, 12″ tilting blade, 50″ rip capacity, belt driven scoring blade, DADO capability, miter gauge, additional table, 5/8″ Arbor



ADVANTAGES

Stabilidy and rigidity
The new saw unit closed loop structure is made of a heavy cast iron and is supported firmly under the table by two lateral supports in a crescent shape. These solutions give strength and rigidity, guaranteeing perfect cutting results. The saw unit can be equipped, on request, with scoring blade for perfect cutting even on veneered panels. The scoring blade is an optional available in two versions: with belt transmission from the main motor and with an independent motor 0.75 HP (0.55 kW). The maximum diameter allowed for the main saw is 315 mm with scoring blade mounted.

Precise and silent
Optimal support also to larger pieces, with the sliding table 360 mm wide. Exceptional precision and smoothness: to secure the guides it is not used glue, since the thickness could affect sliding. They are secured with a procedure of aluminum riveting.

The large square frame
Panel loading is easy on the large squaring frame with an idle roller at the end. The telescopic squaring fence with two reversible stops can be used to square panels measuring 3200 x 3200 mm and for miter cuts at up to 45° on both sides of the frame.

High-tech devices
The support of the fence can also be equipped with a digital readout with the sensor running on a magnetic band.

Technical data

sc 4e
Max. sawblade diameter with scoring blade installed mm / inches 315 / 12
Sawblade arbor size inches 5/8″ Arbor
Max. sawblade projection from table at 90°/45° mm / inches 100/70 3.94/2.75
Cutting width on parallel fence (Rip capacity) mm / inches 1270 / 50
Max. squaring stroke of sliding table saw mm / ft 2600 / 8.5
Single-phase motor Hp 4.8

Please Contact us for a shipping quote for Pre-Owned Machinery and or New machinery below $6,000.

***Some restrictions apply for free freight on NEW machinery over $5,999. FREE freight is to a commercial address with a dock and or forklift. EXTRA FEES may apply to accessorials like restricted access, residential drops, liftgates, and excessive lengths.

Applies to lower 40 of the contiguous states only. AZ, CA, ID, MT, NV, OR, UT, & WA do not qualify for free shipping. We can split ship to these states from $5,999 and up. Free shipping does not apply to RazorGage, Oliver, nor JLT Machinery or other machines listed as not free shipping.

360 Degree Machinery offers financing solutions with competitive rates, flexible terms, and a simple application. Take the hassle out of machinery purchases. Click Here to learn more now!

ADVANTAGES

Stabilidy and rigidity
The new saw unit closed loop structure is made of a heavy cast iron and is supported firmly under the table by two lateral supports in a crescent shape. These solutions give strength and rigidity, guaranteeing perfect cutting results. The saw unit can be equipped, on request, with scoring blade for perfect cutting even on veneered panels. The scoring blade is an optional available in two versions: with belt transmission from the main motor and with an independent motor 0.75 HP (0.55 kW). The maximum diameter allowed for the main saw is 315 mm with scoring blade mounted.

Precise and silent
Optimal support also to larger pieces, with the sliding table 360 mm wide. Exceptional precision and smoothness: to secure the guides it is not used glue, since the thickness could affect sliding. They are secured with a procedure of aluminum riveting.

The large square frame
Panel loading is easy on the large squaring frame with an idle roller at the end. The telescopic squaring fence with two reversible stops can be used to square panels measuring 3200 x 3200 mm and for miter cuts at up to 45° on both sides of the frame.

High-tech devices
The support of the fence can also be equipped with a digital readout with the sensor running on a magnetic band.

Technical data

sc 4e
Max. sawblade diameter with scoring blade installed mm / inches 315 / 12
Sawblade arbor size inches 5/8″ Arbor
Max. sawblade projection from table at 90°/45° mm / inches 100/70 3.94/2.75
Cutting width on parallel fence (Rip capacity) mm / inches 1270 / 50
Max. squaring stroke of sliding table saw mm / ft 2600 / 8.5
Single-phase motor Hp 4.8
