Laguna Tools X|Flux: 10HP Dust Collector

$13,999.00

The X|Flux dust collector is your solution for high filtration efficiency in large shops and enclosed areas.

Features:
  • Motor HP: 10 HP
  • Phase: 3
  • Voltage: 220V
  • Amps: 28 Amps
  • Recommended Breaker: 50 AMP
  • Hertz: 60
  • Plug: No
  • RPM: 3450
  • Main Motor Switch: Radio Frequency
  • Control Panel: Anodized Aluminum
Guaranteed Safe Checkout

Credit

Laguna Tools X|Flux: 10HP Dust Collector
$13,999.00
Request a call back
(*Optional)

Hand Held Remote Control: HF (High Frequency)

LED Warning Light Empty Drum: Yes

Canister Auto Clean Controlled By Timer: Yes

Shop Setting CFM: 4700

Inlet CFM: 8070

Max Static Pressure (Inches of Water): 11″

Impeller/Fan Size: 15-½″

Impeller Material: Steel

Impeller Type: Radial Fin

Balancing of Fan: ISO 1940

Inlet Diameter: 12″

Drum Capacity: 54 Gal x 3

Octagon Drum: Low Pressure Suction, Swiveling Casters

Drum Collection Bag (Dia. x L): Plastic Bag 29″ x 51″

Canister Filter Type: White 1 Micron

Filtration Efficiency: 0.2-2 Micron (@99.97%)

MERV Rating: 12

Canister Diameter: 500mm (19.69″)

Canister Length: 900mm (35.43″)

Canister Cleaning: Timed Auto Clean 2 x 10 Seconds Per Work Hour

Canister Filter Lower: Plastic Bag 29″ x 24″

Wheels: 6″ Industrial Swiveling

US/CSA Approved: Yes

Decibel Reading: 80dB(A)(@9.8′)

Assembled Dimensions (L x W x H): 104″ x 49″ x 106″

Machine Weight: 750 kgs/ 1653 lbs

Shipping Weight: 830 kgs/ 1829 lbs
