Description
Semi-automatic non-ferrous saw that’s user friendly for set up and operation. Featuring two removable surface wear plates, heads that rotate 45°, three gib guides, and a manual oiler.
Features
- Outboard section of the table is designed so shorter lengths tumble down a mesh discharge chute
- Manual oiler to lubricate 1” thick, hardened vertical ways
- 3.5/4.5 HP motor has the muscle to drive a 14½” or 12” blade quickly and quietly through solids
- Clear acrylic hood has shock assists for raising and lowering and electrical interlocks
- Table features two removable surface wear plates to support longer cut lengths
- Three gib guides for the cutting head with two adjustable cast iron gib blocks in each for increased cutting accuracy and easy adjustment
- Rear surface of the gearbox is machined with interlocking circles to evenly distribute oil over the ways
- Large automatic clamping vise features adjustable gib guides, removable face plates, and an anti-burr arm
- Swap cutting head to gain non-ferrous/ferrous option on same saw
- Ability to add a programmable feed system to make fully automatic with wide range of capabilities
Standard Equipment
- Blade
- Coolant
- Saw blade selector calculator
- Tools kit for changing blades
- Instruction and service manual
- Adjustale positive stop
Specifications
- Cutting Ability: Non-Ferrous/Plastic
- Max Blade Diameter: 14½”
- Max Vise Opening: 8¾”
- Max Angle: 45° Left
- Slotting: No
- Speeds: 1.500/3,000 rpm
- Work Height: 35”
- Electrical Requirements: 220V Three Phase 3.5HP
- Machine Dims: 28” x 39” x 73”
- Approx Weight: 1,360 lbs
Capacities
- Solid Round
- 90°: 4¼”
- 45°: 3-5/8”
- Tube
- 90°: 5-1/16”
- 45°: 5”
- Square
- 90°: 4¼”
- 45°: 3-7/8”
- Rectangle
- 90°: 4” x 7”
- 45°: 4” x 6”
Optional Add-Ons
- 440V unit available (please contact a sales rep for more info)
- Ferrous Cutting Head (300128)
- Non-Ferrous Cutting Head (79917)
- Loading Table (301644)
- Unloading Table (301645)
- Second Main Vice (300196)
- Mist Kit (77178)
