Main Belt Motor
Driving the heart of the ENDURO machines, the sanding belt is powered by a main motor up from 20HP – 30HP. In combination with the Conveyor Belt Motor, even heavy drossing can’t stop this machine from finishing your pieces exactly how you need it.
Front Control Panel
Easy one push +/- .005 height adjustments and auto-height detection, the Control Panel on the ENDURO makes getting the perfect height happen in seconds.
Auto-Height Adjustment
To get the most accurate sanding or finishing possible, the ENDURO is able to automatically adjust the table height according to what tolerance you need.
Main Motor: 30HP (3 Phase)
Feed Speed: 2HP (3 Phase)
Table Lifting Motor: 1/4HP
Programmable Logic Control: Yes (Digital Readout)
Automatic Thickness Control: Yes (Thicknessor)
Max Sanding Height: 6″
Min Sanding Height: 26 Gauge
Max Sanding Width: 51″
Sanding Belt Size: 75″
Diameter of Sanding Drum: 8″
Length of Sanding Drum: 52.1″
Sanding Drum RPM: 1720
2 Speed Settings (Low/High): 14-60 FPM
Dust Port Size: 5″
Number of Dust Ports: 8
Foot Print: 68″ x 20-1/2″
Conveyor Height At Lowest Setting: 31.9″ (37.4″ Table Height)
Steel Cabinet: Yes
Operating Air Pressure: 60PSI
Sanding Belt Oscillation: Yes
Sanding Belt Motor Brake: Yes
CSA: Yes
Net Weight: 2976 lbs.
Shipping Weight: 3527 lbs.
