Laguna U|30 Metal Dust Collector
Laguna U|30 Metal Dust Collector
$2,999.00
The Laguna U|30 is a 3 HP metal dust collector that moves up to 957 CFM through four 4-inch inlets, built for shops running several machines at once. A fire-resistant galvanized micro-mesh filter and roll-out 5.6-gallon debris drawer handle abrasive metal dust, and it runs on 220V single-phase power at a manageable 74 dB.
Specs & Features
Laguna U|30 Metal Dust Collector Overview
A shop can outgrow a single-machine dust collector fast. The U|30 is built for the next step up: enough suction to keep several grinding, sanding, and deburring stations clear at once, while still running on single-phase 220V power. A fire-resistant filter and roll-out debris drawer handle the abrasive dust these machines throw off. The sections below detail its airflow and inlets, the metal-dust construction, and shop-floor handling. 360 Degree Machinery is an authorized Laguna distributor.
Power for Multiple Machines
A 3 HP induction motor drives a 12-inch impeller to move up to 957 CFM. Four 4-inch inlets let you connect several machines at once, so a fabrication shop can tie in grinders, sanders, and a deburring table without starving any one tool for suction.
Built for Metal Dust
The U|30 uses a galvanized micro-mesh filter that resists sparks and captures fine metal dust, which matters when you are collecting abrasive, spark-prone swarf. A heavy steel cart and steel cabinet hold up to daily use, and the 5.6-gallon debris drawer rolls out for quick emptying. Casters on both the machine (2.5 inch) and the drum (2 inch) make it easy to move and service.
Shop-Ready Operation
Despite its power the U|30 runs at 74 dB, and a magnetic switch protects the motor. It ships without a plug, so you can wire it to your shop’s 220V service.
Specifications
| Motor | 3 HP |
|---|---|
| Motor Speed | 3,450 RPM |
| Electrical | 220V / 60 Hz / 1 Ph |
| Amps | 10 A |
| Switch | Magnetic |
| Power Cord | 6 ft (no plug) |
| Inlets | (4) 4″ |
| Maximum Air Flow | 957 CFM |
| Static Pressure | 6.9″ H2O |
| Impeller | 12″ diameter |
| Collection Volume | 5.6 gallons |
| Filter Material | Galvanized micro-mesh (fire-resistant) |
| Filter Size | 19.25″ x 25″ x 1.8″ |
| Construction | Steel cart, stainless drum |
| Noise Level | 74 dB |
| Casters | 2.5″ machine / 2″ drum |
| Start Capacitor | 600 µF / 125V |
| Run Capacitor | 450 µF / 350V |
| Footprint (L×W×H) | 33.5″ x 25″ x 40″ |
| Shipping Size (L×W×H) | 35″ x 26″ x 42″ |
| Net Weight | 230.5 lb |
| Gross Weight | 253.5 lb |
Contact 360 Degree Machinery
360 Degree Machinery is an authorized Laguna distributor. Call us at 630-229-6705 for current pricing, a recommendation, or to request a quote on the Laguna U|30 Metal Dust Collector.
