Doucet “SDM-M-1-30-72” Mitered Door Clamp

This is a harder to find machine in the marketplace. Designed for the quick and accurate clamping & squaring of miter and regular cabinet doors. This particular SDM is optioned with an additional vertical clamp for a total of (3).

5-1/2″ x 5-/1/2″ minimum door size with small part insert (not included), 5-1/2″ x 18-/1/2″ minimum door size with all (3) vertical clamps installed, 30″ x 72″ maximum door size, 3-position pneumatic valve operates clamp in open, pre-clamping, & clamping modes, (4) clamps (1 fixed vertical, 1 fixed horizontal, 1 mobile vertical, 1 mobile horizontal) ride on roller bearings for effortless positioning, corner adjustment made easy by push button action.

This fully functional machine has been fully cleaned, checked, and is ready to work from the time you receive it. This is our guarantee to both you and your company. It is owned by 360 Degree Machinery and located in our inventory in Kingston, TN.
