COIMA USA F Series Dust Collectors

COIMA USA F Series Dust Collectors

SKU N/A Categories Coima Dust Collection, Coima USA, Dust Collectors & Accessories Tags Dust Collection, Dust Collectors, Free Shipping* Brand Coima USA

The Coima F-380 and F-450 offer wheeled metal bins on the standard models. Other options include a “Big Bin Version”, “Hopper with Rotary Air Lock”, and a “Hopper with a Screw and Transfer Fan.”

F-380 – 5,500 CFM @ 13″ (static pressure)

F-450 – 7,100 CFM @ 11″ (static pressure)

Reliable, silent, and easy to use. With its compact design to suit any environment, even inside production facilities, its highly effective operation in just a small space, the F Series is ideal for extracting various types of shavings and dust. Built in painted metal paneling and equipped with the following:

Settling chamber for the decanting of shreds into the filtering unit.
Filtering media in antistatic polyester (needle felt sleeves 500 gr/m², cartridges 270 gr/m²)
Automatic programmable counter current compressed air cleaning system
Continuous discharge of the shavings and dust into handy wheeled metal bins with sight glass to check the filling level.
Manual cleaning system of the filter by compressed air jet pulses
(Standard Model) Continuous chip and dust discharge in a wheeled metal bin with viewing window to check the filling level.

Model/Motor: No selection

More options

Clear

Price available upon request.

Add to Quote Request

Specs & Features

Description

The F-Series Compact Enclosed Dust Collector are designed for efficient filtration in smaller spaces than traditional baghouse or cyclone collectors. Their compact profile makes these units suitable for use inside workshops and factory production areas. Thanks to COIMA’s advanced engineering they are reliable, quiet, and easy to use.

The F-Series dust collector is suitable for the extraction of various dusts and chips, and feature durable construction with 14 GA galvanized steel sheet panels over a 12 GA frame. The needle felt bag (F250 & F320) or cartridge (F380 & F450) filters are automatically cleaned by a programmable pulse-jet cleaning system.

The F-Series also includes an emergency flooding system for interconnection with spark detection and extinguishment systems (ideal for NFPA compliance). The high efficiency backward inclined centrifugal fan includes noise reduction insulation, and is located inside the dust collector housing. This configuration allows for higher negative pressures as compared to similar collection systems.

Shipping

FREE SHIPPING DOES NOT APPLY TO PRE-OWNED MACHINERY

Please Contact us for a shipping quote for Pre-Owned Machinery and or New machinery below $6,000.

***Some restrictions apply for free freight on NEW machinery over $5,999. FREE freight is to a commercial address with a dock and or forklift. EXTRA FEES may apply to accessorials like restricted access, residential drops, liftgates, and excessive lengths.

Applies to lower 40 of the contiguous states only. AZ, CA, ID, MT, NV, OR, UT, & WA do not qualify for free shipping. We can split ship to these states from $5,999 and up. Free shipping does not apply to RazorGage, Oliver, nor JLT Machinery or other machines listed as not free shipping.

Literature, Manuals, and or Drawings

Financing & Leasing Options for Your Convenience!

360 Degree Machinery offers financing solutions with competitive rates, flexible terms, and a simple application. Take the hassle out of machinery purchases. Click Here to learn more now!

Description
Additional information

Description

The F-Series Compact Enclosed Dust Collector are designed for efficient filtration in smaller spaces than traditional baghouse or cyclone collectors. Their compact profile makes these units suitable for use inside workshops and factory production areas. Thanks to COIMA’s advanced engineering they are reliable, quiet, and easy to use.

The F-Series dust collector is suitable for the extraction of various dusts and chips, and feature durable construction with 14 GA galvanized steel sheet panels over a 12 GA frame. The needle felt bag (F250 & F320) or cartridge (F380 & F450) filters are automatically cleaned by a programmable pulse-jet cleaning system.

The F-Series also includes an emergency flooding system for interconnection with spark detection and extinguishment systems (ideal for NFPA compliance). The high efficiency backward inclined centrifugal fan includes noise reduction insulation, and is located inside the dust collector housing. This configuration allows for higher negative pressures as compared to similar collection systems.

Additional information

Model/Motor: No selection	5,500 CFM F-380, 7,100 CFM F-450
