| Manufacturer | AMT by Gorman-Rupp |
|---|---|
| SKU | 2874-95 |
| Model Number | 2874-95 |
| For Potable Water Use | No, Clients incorrectly utilizing Non-Potable Water Pumps For Human Consumption Drinking Water Applications (POTABLE) bear 100% liability for this unlawful practice. Absolute Water Pumps excludes associated liabilities, returns, &/or refunds. |
| Engine/Motor Brand | AMT by Gorman-Rupp |
|---|---|
| Fuel Type | Electric |
| Engine/Motor Type | Totally Enclosed Fan Cooled (TEFC) |
| Starting System | NA |
| Horsepower | 3.0 HP |
| Phase | 3-Phase |
| Voltage | 208 Volt (3-Phase), 230 Volt (3-Phase), 460 Volt (3-Phase) |
| Frequency | 60 Hz or 50 Hz (See Spec For Details) |
| Rated Current | 10/5 Amps |
| NEMA Frame | 182JM |
| RPM | 3450 |
| Pump Type | Self-Priming Pump |
|---|---|
| Pump Style | Electric Centrifugal Pump |
| Inlet Diameter | 3″ |
| Outlet Diameter | 3″ |
| Max Gallon Per Min (GPM) (See Pump Curve For Your Duty Point Estimates) | 230.0 |
| Max Total Head (Static) | 65 Feet |
| Maximum Pressure (PSI) | 28 |
| Max Suction Lift (Static, Wet, @ Sea Level) | 20 Feet |
| Solids Handling | Yes |
| Max Solids Handling (Inches) | 0.375″ |
| Self Priming Pump | Yes, Wet Prime |
| Back Flow Check Valve | Yes |
| Pump Housing Drain | Yes |
| Housing Material | Cast Iron |
| Impeller Type | Semi-Open, Self-Cleaning |
| Impeller Material | Stainless Steel |
| Volute Material | Double |
| Seal Material (Mechanical Or Other) | Buna-N |
| Shaft Seal | Buna-N/SS |
| Temperature Range | To 180 F |
| Port Type(s) | Discharge: Female (NPT), NPT |
