Oliver Shaper – 4705.002 – 7.5HP, 3Ph

Oliver Shaper – 4705.002 – 7.5HP, 3Ph

Price range: $5,199.99 through $5,574.99

SKU N/A Categories , , Tag Brand:
  • Massive cast iron precision ground table provides a solid work surface.
  • Table features pre-drilled and threaded holes for power feeder.
  • Cast iron base provides a steady platform.
  • Table features pre-drilled and threaded holes for optional power feeder.
  • 3/4” and 1-1/4” interchangeable spindles are included for added versatility.
  • Three spindle speeds allow more choices to produce a better finish.
  • Reversing spindle gives more options for each set-up.
  • Innovative dovetail design accurately raises and lowers the spindle.
  • Fence is independent and features micro adjustments for quick set-up.
  • Top mounted control panel includes a digital readout for spindle height.
  • Large hand wheel for quick spindle height adjustment.
  • Miter gauge included.
  • Magnetic controls with emergency off switch for safer operation.
  • Powerful TEFC motor available in single phase.
Add to Quote Request

Model Number 4705
Ph 3Ph
Stock No. (7.5HP, 3Ph) 4705.002
Spindle Speeds 5,000, 7,000, 10,000 RPM
Maximum Tool Diameter 7” Below Table, 8” Above Table
Spindle Diameter: 1-1/4” and 3/4” Interchangeable
Verticle Spindle Travel: 4″
Spindle Direction: Reversible
Table Height 36-1/2”
T-Slot: 3/4” x 3/8”
Dust Port Diameter 4”
Minimum CFM: 800
Footprint 28-1/2”L x 24-3/4”W
Table Dimensions 39”L x 31-1/2”W
Motor 3Ph 7.5HP, 220/440V*, Prewired 220V (16.8/8.4 Amp)
Net Weight 660 lbs.
Gross Weight 800 lbs.

Please Contact us for a shipping quote for Pre-Owned Machinery and or New machinery below $6,000.

***Some restrictions apply for free freight on NEW machinery over $5,999. FREE freight is to a commercial address with a dock and or forklift. EXTRA FEES may apply to accessorials like restricted access, residential drops, liftgates, and excessive lengths.

Applies to lower 40 of the contiguous states only. AZ, CA, ID, MT, NV, OR, UT, & WA do not qualify for free shipping. We can split ship to these states from $5,999 and up. Free shipping does not apply to RazorGage, Oliver, nor JLT Machinery or other machines listed as not free shipping.

Financing & Leasing Options for Your Convenience!

360 Degree Machinery offers financing solutions with competitive rates, flexible terms, and a simple application. Take the hassle out of machinery purchases. Click Here to learn more now!


Model Number 4705
Ph 3Ph
Stock No. (7.5HP, 3Ph) 4705.002
Spindle Speeds 5,000, 7,000, 10,000 RPM
Maximum Tool Diameter 7” Below Table, 8” Above Table
Spindle Diameter: 1-1/4” and 3/4” Interchangeable
Verticle Spindle Travel: 4″
Spindle Direction: Reversible
Table Height 36-1/2”
T-Slot: 3/4” x 3/8”
Dust Port Diameter 4”
Minimum CFM: 800
Footprint 28-1/2”L x 24-3/4”W
Table Dimensions 39”L x 31-1/2”W
Motor 3Ph 7.5HP, 220/440V*, Prewired 220V (16.8/8.4 Amp)
Net Weight 660 lbs.
Gross Weight 800 lbs.

Additional information

Voltage: No selection

230V Standard, 460V Upgrade + $375.00
