JLT #79F-16-PC – 16′ Rail & Post Custom Clamping System with 36 Clamps

$10,950.00

Features:

  • (5) total gluing levels.
  • Includes (36) 3 1/2″ High Jaw 40″ opening clamps
  • Innovative, Space Saving Feature that allows the Clamps to be hung Vertically when not in use
  • Taylor’s Patented and Successful Clamp Arm Design
  • Versatility to Edge Glue or Face Glue Hundreds of Woodworking Components
  • 100% steel tubular construction.
  • Accessories: #302-40-H-R Clamps, 138B, 150B Glue Spreaders, 180A, 79-16 Hold downs, 80-1706 Rocker Plates



Machine Footprint: 196″L x 70″H x 48″W

(Additional Features and Details Below)

Guaranteed Safe Checkout

Credit

JLT #79F-16-PC – 16′ Rail & Post Custom Clamping System with 36 Clamps
$10,950.00
Request a call back
(*Optional)
  • Highest Production JLT clamping system for the Medium Size Shop.
  • BEST VALUE and our MOST VERSATILE
  • Edge Glue and Face Glue a variety of solid wood components
    • Produce 84+ edge glued panels per day with a Standard Setup
    • Face Glue, Utilizing our Rocker Plates, a Wide Variety of Railing Stock, Posts, Beams, Flooring Blanks, and more
  • Includes (36) 3 1/2″ High jaw 40″ Clamps
    • Optional 52″ Clamps Available on Request
    • Each Clamp Arm INCLUDES Rocker Plate Jaw Extensions for Face Gluing
  • Free Standing Unit with 3000 lbs. Weight Capacity
  • 100% Complete Tubular Steel Construction
  • Put (2) 12′ Panel Clamps side by side for edge gluing up to 24′ long Products
  • Complete 3 Year Warranty
  • Accessories: #302-40-H-R Clamps, 138B 8″ x 48″ Taylor Plate Spreader, 150B Glue Spreader, 180A Pneumatic Panel Flattener, 79-16 Holddowns, 80-1706 Rocker Plates
  • Standard Stock Size of 40″ Maximum Opening
    • Additional Stock Size is 52″ Maximum Opening
    • Additional non-stock and Custom Sizes from 32″ – 120″ Opening
    • Minimum Clamp Opening of 9″
  • Robotically Welded / 100% Steel Construction
    • Lifetime Warranty on all Welded Components
    • Guaranteed never to Twist, Bow or Bend under normal working conditions
  • Each Clamp can Produce up to 3000 lbs of Clamping Force
  • Patented Equalizer Design Provides Equal Clamping Force from the Front and Rear Jaws
    • Higher Quality Panels result from this Design with more even Glue Line Pressure
