Features:
- Main Motor: (2) 20HP, 3PH, 460V
- 30 Amp
- Max. Workpiece Size: 11-3/4″ (W)” x 8″ (H)
- Saw Wheels: 1″ x 28″
- Saw Blade Size: 1″ x 168″ Carbide Tipped Blade
- Distance from upper blade to conveyor table: .35” – 6.7” (9mm – 170mm)
- Distance from lower blade to conveyor table: 3/16” – 4” (4.5mm – 125mm)
- Distance between two blades: Minimum 3/16” (4.5mm)
- Saw wheel width: Accepts 1” or 1 ¼” blades
- Conveyor belt size: 11.8” W x 215 ¾” L (300mm x 5480mm)
- Min. cutting Thickness: 0.35″
- 3HP Inverter Controlled Variable Hydraulic Feed of 5-80 FPM
- Controlling Blade Tension: Hydraulic Tensioning System
- Elevation: (2) 1/4 HP motors with 525 digital set position controls
- Dust Ports: (4) 4″ ports requiring 436 CFM at each point of extraction
- Machine Dimensions: 109″(L) x 82″(W) x 85″(H)
- Machine Weight: 3,080 lbs.
- Packing Dimensions: 115″ x 85″ x 79″
- Packing Weight: 3,400 lbs.
- (1) Toolbox
- Warranty is one-year parts
- All machines are tested stateside prior to shipment providing trouble-free start-up.
Specifications:
- Top Head Hp. = 20 Hp.
- Bottom Head Hp. = 20 Hp.
- Voltage/ Freq. = 460 Volt 60Hz
- Phase = 3 Phase
- Amp Requirement = 29 Amps
- Feed Hp. = 3 Hp.
- Feed System = 11” x 218” Hydraulic Drive Belt
- Drive System = 3 Hp. Hydraulic Pump
- Feed Speed = 15 – 80 FPM
- Variable Speed = Hydraulic Adjustment Knob
- Elevation Hp. = 1/4 Hp.
- Elevation Style = (2) CH-525 Elevation Control
- Elevation Sys. = (4) Post Jack Screw
- Total Hp. = 43.5 Hp.
- Electronics = CE Approved Components
- Control Voltage = 230 Volt
- Assisted Start = Wye Delta
- Programmable = Elevation
- Operator Panel = Fixed
- Throat Capacity = 11-3/4” x 8”
- Min. Length = 18”
- Max. Length = Infinite
- Min. Width = 1″
- Max. Width = 11-3/4”
- Min. Thickness = 3/16″
- Max. Thickness = 8”
- Blade Size = 1” x 168”
- Tooth Spacing = 5/8 In.
- Blade Kerf = .063 In.
- Blade Speed = 6300 RPM
- Tracking Style = Manual Adjustment
- Tension Style = Hydraulic Tension
- Dust Collection = (4) 4” @ 1744 CFM
- Dust Port Out = (4) 4” Ports
- Arbor Diameter = 2″ Arbor
- Digital Display = Elevation
- Conveyor = 15-1/4” x 215-3/8”
- Hold Down Style = Pneumatic / Gravity
- FLR Included = Filter, Lubricator, Regulater
- Recommended CFM = 1744 Total CFM
- Emergency Stop = Push Button
- Rear E Stop = Push Button
- Guarding = Full Cabinet Enclosure
- Oiler = Blade Oil Mister
- Fence Type = Steel
- Fence Dims. = 6-1/2” Tall
- Blade Guide = Steel Blade Guides
- Wheel Dims. = 1” x 28”
- Wheel Cnstr. = Steel Construction
- Frame Const. = 3/16” Steel Construction
- Table Const. = Steel
- Infeed Table = 11-1/4” x 109”
- Decible Rating = 79 dB
- Net Weight = 3080 Lbs.
- Gross Weight = 3400 Lbs
- Machine Dims. = 109” x 82” x 85”
- Packaging Dims = 115” x 85” x 79”
