- High Production clamping system for the Medium Size Shop.
- BEST VALUE – Our Most Popular Panel Clamp Model
- Edge Glue and Face Glue a variety of solid wood components
- Produce 72+ edge glued panels per day with a Standard Setup
- Face Glue, Utilizing our Rocker Plates, a Wide Variety of Railing Stock, Posts, Beams, Flooring Blanks, and more
- Includes (30) 3 1/2″ High jaw 40″ Clamps
- Optional 52″ Clamps Available on Request
- Free Standing Unit with 3000 lbs. Weight Capacity
- 100% Complete Tubular Steel Construction
- Put (2) 12′ Panel Clamps side by side for edge gluing up to 24′ long Products
- Complete 3 Year Warranty
- Accessories: #302-40-H-R Clamps, 138B 8″ x 48″ Taylor Plate Spreader, 150B Glue Spreader, 180A Pneumatic Panel Flattener, 79-16 Holddowns, 80-1706 Rocker Plates
- Standard Stock Size of 40″ Maximum Opening
- Additional Stock Size is 52″ Maximum Opening
- Additional non-stock and Custom Sizes from 32″ – 120″ Opening
- Minimum Clamp Opening of 9″
- Robotically Welded / 100% Steel Construction
- Lifetime Warranty on all Welded Components
- Guaranteed never to Twist, Bow or Bend under normal working conditions
- Each Clamp can Produce up to 3000 lbs of Clamping Force
- Patented Equalizer Design Provides Equal Clamping Force from the Front and Rear Jaws
- Higher Quality Panels result from this Design with more even Glue Line Pressure
