Northtech NT AW-400PBX Horizontal Bandsaw
The Northtech NT AW-400PBX Horizontal Bandsaw features a powerful 40 HP motor to drive the 2” x 208″ blade at speeds from 4700 – 6750 FPM. The 15-1/4′ (W) feed belt is driven by an inverter-controlled 3 HP motor for easy operator-adjustment between 0 to 120 FPM. Motorized elevation adjustment and return conveyor are also included.
ⓘ Unlock Your Best Price!
By clicking the button below, you'll receive personalized pricing tailored to your needs, including available discounts and accurate shipping costs. We're committed to offering you the best value, but some of our special rates can't be displayed online.Don't miss out – request your quote now!
Specifications:
- Main Motor Hp. = 40 hp.
- Voltage/ Freq. = 460 Volt 60Hz
- Phase = 3 Phase
- Amp Requirement = 65 Amps
- Feed Hp. = 3 Hp.
- Feed System = 15-1/4” x 215-3/8” Belt
- Drive System = Motor Mated to Gear Box
- Feed Speed = 0 – 120 FPM
- Variable Speed = Inverter Controlled
- Elevation Hp. = 1 Hp.
- Elevation Style = CHPC-535 Elevation Control
- Elevation Sys. = (2) Post Jack Screw
- Total Hp. = 45 Hp.
- Electronics = UL Approved Components
- Control Voltage = 220V Control Voltage
- Min. Length = Individual Feed 20”
- Min. Width = 2″
- Max. Width = 17-1/2”
- Min. Thickness = 1/8”
- Max. Thickness = 10”
- Blade Size = 2” x 208”
- No. of Teeth = 208
- Tooth Spacing = 1”
- Blade Kerf = .086 In.
- Blade Speed = 4700 – 6750 FPM
- Tracking Style = Manual Adjustment
- Tension Style = Pneumatic / Hydraulic Tension
- Vertical Travel = 1/8” – 10”
- Dust Collection = (2) 6” @ 1962 CFM
- Dust Port Out = (2) 6” Ports
- Digital Display = Elevation
- Conveyor = 15-1/4” x 215-3/8”
- Hold Down Style = Pneumatic / Gravity
- FLR Included = Filter, Lubricator, Regulator
- Recommended CFM = 1000 CFM @ Extraction Point
- Emergency Stop = Push Button
- Rear E Stop = Push Button
- Guarding = Full Cabinet Enclosure
- Oiler = Blade Oil Mister
- Tiltable = 30 Degree Tilt
- Blade Guide = Steel Blade Guides
- Wheel Dims. = 1-3/4” x 33-1/2”
- Wheel Cnstr. = Steel Construction
- Frame Const. = 1/4” Steel Construction
- Worktable Dims. = 15” x 109”
- Table Const. = Steel
- Return Conveyor = 7-1/4” x 218” Belt
- Decible Rating = 80 dB
- Net Weight = 3674
- Gross Weight = 4090 Lbs.
- Machine Dims. = 117” x 100” x 88”
- Packaging Dims = 120” x 102” x 90”
