Airflow 5000CFM @ 6”wc
The 15″ inlet has a net airflow of 5000CFM with a static pressure of 6″wc. A typical CNC Router needs a minimum requirement of 1500CFM, while a typical 37″ wide belt sander would call for a minimum 2000CFM. This makes the I|Flux: 10 Elite a great fit for a CNC Router-based cabinet shop that would be running several tools at once.
Fine Dust Ready
With fine dust, the key is to have a large filter surface area and to keep those filters clean. The smaller tube filter design of the I|Flux:10 Elite is designed for the fine dust to cake on the inner side of the filters and fall into the bin as the mass grows. The filter surface area of the I|Flux: 10 Elite is 409 square feet. A typical 5HP dust collector has a surface area of 260 square feet. This increase in filter area translates to a large increase in airflow, making the I|Flux an ideal machine for fine dust applications.
Quick Lever Waste Bins
Changing the waste bins has never been easier. Deactivate the air-tight seal by pulling up the release bar and rolling out the bin. The positive pressure design means there is no need for a bag hold-down system like in a multi-stage system. The wheels swivel 360 degrees and are mounted on a sturdy base to ensure they work in your shop for many years.
Additional Features
The I|Flux:10 Elite fine dust collector displays an amperage readout on the control panel. This allows the user to monitor the efficiency of the motor. A high-frequency remote is also included so the operator can turn the machine on and off within a 60-meter range.
Safety
There are several NFPA standards in place to ensure the proper installation and use of a dust collector. For woodworkers, the standard is NFPA 664: Standard for the Prevention of Fires and Explosions in Wood Processing and Woodworking Facilities. The I|Flux: 10 Elite complies directly with this standard. In addition, the I|Flux is fitted with a phase controller and TEFC motor for added electrical safety.
