Maggi Boring System 29
$9,190.00
Maggi System 29 Construction/Line Borer
Efficient and durable with an unbeatable price-performance ratio. Maggi single-head boring machines are simple, compact solutions, ideal for those who manufacture custom-made furniture and furnishings.
$249 Flat Rate Shipping!
*within the continental United States on Maggi Technology products onlyFor current product availability and our most competitive price delivered, please contact us using the “Request A Quote” button below. Due to vendor restrictions, we cannot always advertise our highly competitive pricing online.
The Maggi System 29 Boring Machine provides a 29 spindle 32 mm universal drilling solution, with horizontal and vertical boring capabilities and pneumatic tilting of the boring unit with locking points from 0 to 90 degrees for quick set-up at any angle.
Features:
- Accurate Positioning Of The Boring Unit To The Table With Digital Readout.
- 0 To 2.5″ Adjustable Drilling Depth With Patented Spiral Setting Device.
- (3) Patented Quick Release Material Clamps With Auto-Setting To Firmly Hold Material To Table.
- Powerful 2 HP Motor.
- 47″ X 13″ Cast Iron Table.
- Side Fences With Mechanical Digital Readout For Quick And Accurate Setting.
- 120″ Line Boring Fence With (4) Stops.
- Foot Actuated Pneumatic Clamps And Drill Cycle.
- Includes Magnetic Motor Starter With Overload Protection And (29) Quick Change Chucks.
Specifications:
Spindle Spacing: | 1-1/4″ (32mm) |
Dust Outlet: | 3″ |
Net Weight: | 705 Lbs |
Dimensions: | 59.3″ X 37.8″ X 50″ Tall |
Crated Dimensions: | 59.8″ X 37.4″ X 40.5″ Tall |
Crated Weight: | 815 Lbs |
Options (single head boring machines):
| 36000061 | Extra quick change chucks | Shank Ø 10mm | $24.80 |
| 26054812 | Right aluminum fence with 2 stops | mm 1500 x 40 | $395.00 |
| 26054813 | Left aluminum fence with 2 stops | mm 1500 x 40 | $395.00 |
| 29970302 | Fence extension | mm 1000 | $195.00 |
| 26050801 | Extra stop for aluminum fence | $109.00 | |
| 29971019 | Extra pneumatic holddown clamp | $369.00 | |
| 26001015 | Blocks to lift clamps up to 140 mm from table | $159.00 | |
| 29900100 | Stop reference pin for line boring | $195.00 | |
| 26001071 | Reference stop to match the long panel during transverse boring | $279.00 | |
| 26200070 | Reference gauge for quick and exact set up of the stops on the long fence – BS 21 P | $109.00 | |
| 26000059 | Reference gauge for quick and exact set up of the stops on the long fence – BS 23 | $109.00 | |
| 26001059 | Reference gauge for quick and exact set up of the stops on the long fence – BS 29 | $109.00 | |
| 26001058 | Reference gauge for quick and exact set up of the stops on the long fence – BS 35 | $109.00 | |
| 26000061 | Reference gauge for near fence parallelism | mm 500 | $109.00 |
| 26200069 | Mirror Imaging Device – BS 21 PRESTIGE(Included as standard equipment) | $195.00 | |
| 26000069 | Set of reference fences for mouldings at 45° and 90° | $189.00 | |
| 26000010 | Storage clamp for extension fences 21P, 23, 29, 35 | $129.00 | |
| 26000012 | Storage trays for side fences, system 23, 29, 35 | $159.00 | |
| 26000014 | Tool tray, system 21, 23, 29, 35 | $185.00 | |
| Hinge Boring Head (Blum 00008392) (Grass 00008395) (Salice 00008391) (Hettich 00008393) | $695.00 | ||
| Difference for single phase motor (*) | $799.00 | ||
| Difference for STANDARDS “CSA” 3PH MOTOR (*) | $995.00 | ||
| Difference for STANDARDS “CSA” 1PH MOTOR (*) | $1295.00 |
