• Simply place the parts against the fence, the iGlue will scan and apply glue to either male or female side of the joint automatically, with no programming required
• Working width: 450mm (18″)
• Working thickness: 5-50mm (3/16″ – 2″)
• Working length minimum: 100mm (4″)
• (3) Programmable working speeds
• Maximum operating speed: 1.4in/s
• Multiple glue nozzle applicators for varying customer needs
• Siko counter fence depth setting
• Removable glue catch basin
• Replaceable no drip nozzle
• Glue and water pot on an internal cart system that pulls outside the
machine for easy access
• LED Illuminated working area
• Automatic sleep mode will place the nozzle into a water bath after
5 minutes without use to keep glue tip fresh
• Auto cleaning mode flushes glue out of the system easily
• Single pneumatic connection with FLR included
• Easy smartphone integration for parameter adjustments and maintenance alerts
• Glue reservoir: 10L Adjustable pressure glue pot included
• Water reservoir: 4L Adjustable pressure water pot included
• Recommended glue type: Water soluble PVA glue 8,000mpa s
• Machine / Shipping weight: 436lbs / 528lbs
• Machine / Shipping dimensions (LxWxH): 38″ x 44″ x 18″ / 44″ x 54″ x 26″
• 230V/460V 60HZ 3PH; 200W; 1Amp
