Evans Midwest Model 2480 Over Arm Router

The Evans Midwest 2480 Over Arm Router is a compact, heavy-duty system for quickly cutting sink holes in countertops. The high-frequency router is rated for continuous use and cutting solid core countertops. This machine features a dual pivot joint allowing the operator to easily follow the guide template in virtually any pattern, reducing operator fatigue while maintaining product consistency and accuracy.

The 2480 Over Arm Router includes a pneumatically operated clamping mechanism for securing the countertop and template throughout the cutting process.

Guaranteed Safe Checkout



  • Proven performance and reliability for cutting sink cutouts in all types of countertops
  • High-frequency router for continuous use, and cutting solid core countertops
  • Off the shelf router option available
  • Cutting Surface: 30” x 48”
  • Spindle Motor: 3 HP & Variable Speed


Electrical: 220 Volt 3 Phase
Motor: 3 HP
Required Amps: 10
Max Cut: 30” (deep) x 48” (wide)
Air Requirement: 100 PSI
Drive: Double V-Belt
Working Height: 33”
Foot Print: 65” x 70”
Shipping Weight: 1180 LBS
