Northtech NT ERD 2800 Series Edge Reinforcing Device

NT ERD 2800 Series Edge Reinforcing Device tapes veneer sheets with paper and simultaneously cuts off the waste. Operators can even adjust the width of trimming heads to fit the size of veneer faces as their requirement. The device effectively keeps the edges of veneer faces from splitting with tapes while being transported.

Add to quote

Specifications:

Model：	NT ERD 2800
Veneer Face Length：	600 – 2800 mm (23.62” – ”110.24) (450 ~ 2800 mm for a stand-alone machine.) (17.71” – 110.24”)
Veneer Face Width:	400 – 1400 mm (15.74” – 55.11”)
Veneer Thickness：	0.35 – 2.0 mm (0.013” x 0.078”)
Production Speed：	15 – 25 m/min. (50 – 82 FPM)
Cut-off Each Side：	10 – 300 mm (11.81”)
Electric Power：	approx. 1.1 kw
Compressed Air：	3/8 air line @ 90 Psi.
Working Height：	900 mm (35.43”)
Dimensions (L x W x H)：	4200 x 1200 x 1750 mm (166” x 48″ x 69”)
Net Weight:	approx. 800 kg (1764 Lbs.)
