Northtech NT CutMate 2800 Series Single Knife Veneer Guillotine
Thanks to a partnership with SAVI Industri A/S–boasting the top market share in U.S.A. and UK for veneer guillotines–NT CutMate 2800 Series Single Knife Veneer Guillotines are constructed to maximize operator safety and comfort. All INNOVATOR guillotines employ complete hydraulic control of both knives and pack beam. The pressure of both knife and pack beam is adjustable. Various materials including veneers, paper, plastics and so on can be cut. When coupled with the INNOVATOR Double-Sided Veneer Glue Applicator (GlueMate 700) & Crossfeed Veneer Splicer (UltiMate series), the perfect gluing and jointing result is accomplished with high production efficiency.
ⓘ Unlock Your Best Price!
By clicking the button below, you'll receive personalized pricing tailored to your needs, including available discounts and accurate shipping costs. We're committed to offering you the best value, but some of our special rates can't be displayed online.Don't miss out – request your quote now!
Features:
- 60 mm knife cylinder
- Green cutting indicator
- 150 mm wide pack beam
- JAPAN YUKEN hydraulic system
- With European safety standards
- JAPAN MITSUBISHI PLC control system
- Rigid welded machine body for stable movement
- Safety light barrier of knife and pack beam in front
- Magnetic scale for accurate linear position measurement of the fence
- Adjustable pressure with hydraulic knife and pack beam for all kinds of veneers
- “Safety locker” at the front end of the knife beam (unique and only in innovator’s guillotines)
- Special designed “emergency valve” for knife to minimize operational danger caused by mechanical faults
- Extra safety valve of knife beam with additional safety knife protective cylinder to keep off any drop of knife
- Two-hand operation of the knife and pack beam ： no movement of the pack beam against the veneer pack made immediately when one push button is released
Recommended Option(s):
- SECOND-CUT Technology for thick or especially hard species of veneers cutting available By switching knife beam to second-cut mode, a thin clip of approx. 1 mm is cut off from the veneer pack after the first trim. This unique feature which can only be found in all INNOVATOR’s guillotines is necessary when working with thick or especially hard species of veneers.
Specifications:
| Model： | NT CutMate 2800 |
| Cutting Length： | 2800 mm (110.23”) |
| Daylight Opening： | 120 mm (4.72”) |
| Electric Power： | approx. 7.5 kw |
| Cutting Width： | 25 – 650 mm ( 0.98” – 25.59”) |
| Pack Beam Width： | 150 mm ( 5.90”) |
| Dimensions (L x W x H)： | 4600 x 1750 x 1850 mm (181” x 69” x 73) |
| Net Weight： | approx. 4450 kg (9810 Lbs.) |
