Northtech NT 660S-20HCVS 20 HP Single Surface Planer (w/ Helical Cutterhead Head)
This Northtech NT-660S series single-surface planer opens wide to accept material up to 12″ (H) by 26″ (W). A soft-start 20 HP motor drives the 4″ helical cutter head with six (6) rows of two-sided inserts. The cutter head is dynamically balanced to ensure a quieter operation and smoother cuts. A 2 HP motor provides steady feed rates from 5 to 75 FPM, precisely controlled through a variable frequency drive. Digital displays for both the feed-rate and cutter height allow quick set-up and accurate adjustment.
ⓘ Unlock Your Best Price!
By clicking the button below, you'll receive personalized pricing tailored to your needs, including available discounts and accurate shipping costs. We're committed to offering you the best value, but some of our special rates can't be displayed online.Don't miss out – request your quote now!
Cutter Heads:
- Cutterhead Motor: 20HP, 3PH 230/460 Volt
Features:
- The Helical 4″ cutterhead provides a high chip removal rate, superior surface finish & low noise level (under 85 dba).
- A powerful 20 HP cutterhead motor and 2 HP feed motor makes this planer ideal for heavy-duty planing and meets high production requirements. Arranged with Y-Delta soft start controls (Square D).
- Digital positioning controller for convenient thickness setting (with memory control to 99 thickness settings).
- Variable feed speed is driven by a VFD and TECO inverter duty DC motor (0-90′ min) with an LED readout of feeding speed.
- Powered table elevation for fast and convenient thickness setting. The opening has been increased to 12″ on NT-660S series planers vs. 8″ on the standard NT-660 planers.
- Extra heavy, rib-reinforced cast iron table is surface precision ground. 660S-20HCVS has (4) precision 35mm jackscrews to support the planer’s rugged construction.
- Adjustable bed rollers ensure fast and proper positioning with regard to rough lumber to finished glue panels.
- UV rubber outfeed roller provides an optimum finish with reduced vibration.
- Corrugated sectional infeed roller has an independent yield for running strip stock of varying thicknesses without the danger of kickback.
- Anti-kickback fingers equipped at the infeed end provide added safety for the operator.
- Raising and lowering limit controls for powered table elevation
Specifications:
- Top Head Hp. = 20 Hp.
- Voltage/ Freq. = 230/460 Volt 60Hz
- Phase = 3 Phase
- Amp Requirement = 52.2/26.1 Amps
- Feed Hp. = 2 Hp.
- Feed System = (2) Segmented/(1) Rubber Roll
- Drive System = Belt
- Feed Speed = 5 – 75 FPM
- Variable Speed = Inverter Controlled
- Elevation Hp. = 1 Hp.
- Elevation Style = REC 727M Elevation Control
- Elevation Sys. = (4) Post Jack Screw
- Total Hp. = 23 Hp.
- Electronics = CE Approved Components
- Dual Voltage = 230/460 Volt
- Control Voltage = 110 Volt
- Min. Length = 10”
- Min. Width = 1″
- Max. Width = 26″
- Min. Thickness = 3/16″
- Max. Thickness = 12”
- Cutter Head RPM = 1800 Rpm
- Head Type = Dynamically Balanced Helical Head
- Cutter Head Dim = 4” x 26”
- Cut Head Matl. = Alloy Steel
- Rows of Cutters = 6 Rows
- No. of Inserts = 156 Inserts
- Insert Size = 15 x 15 x 2.5 mm
- Dust Collection = (1) 6” @ 981 CFM
- Digital Display = Elevation and Feed Speed
- Powered Rollers = (3) Top Powered Rollers
- Idle Rollers = (2) Idle Bed Rollers
- Pressure Shoes = 26” Spring Loaded Pressure
- Decible Rating = 70 dB
- Net Weight = 2650 Lbs.
- Gross Weight = 2770 Lbs.
- Machine Dims. = 44” x 39” x 55”
- Packaging Dims = 52” x 51” x 55”
