Laguna Wood Compact 37″ 1K Widebelt Sander
$15,999.00
The Laguna Tools 37″ wide belt sander is a perfect fit for small woodworking shops. The belt length is 60″, which is the same length as several larger machines. The longer belt means it will not only last longer due to more abrasive material, but it will also run cooler.
This machine is equipped with 1 combination head. This means you can sand either using the drum or the sanding platen or both simultaneously. Due to the large HP motor (10 HP), the machine can dimension even wide boards. This is important for customers who do not own a thickness planer. When you use the machine to dimension your work, only very aggressive paper 60 or 80 grit should be used. The heavy carpet feed belt is powered by a separate 1HP motor and has two feed speeds, 15′ and 49′ per minute.
For current product availability and our most competitive price delivered, please contact us using the “Request A Quote” button below. Due to vendor restrictions, we cannot always advertise our highly competitive pricing online.
Features:
| Single Drum | |
| Main motor: | 10HP |
| Feed Motor: | 1HP |
| Table lifting motor: | 0.25HP |
| Voltage: | 220V / 1phase |
| Max sanding height: | 5-9/10″ |
| Min sanding height: | 1/4″ |
Specifications:
| You can adjust the thickness in 3 ways: | |
| 1) Manual hand-wheel on the bottom of the machine. | |
| 2) By pressing the up or down arrow, the table will move in the desired direction. By tapping these same arrows, the machine will move an exact amount each tap. | |
| 3) The auto thickness gauge will measure your wood piece and automatically set the table to the thickness of the piece of wood inserted. | |
| Max Sanding Width: | 36-½″ (927mm) |
| Sanding Belt Size: | 37″ x 60″ (940 x 1524mm) |
| Adjustable Sanding Platen: | 3″ (77mm) |
| Diameter of Sanding Drum: | 4″ (101mm) |
| Length of Sanding Drum: | 37″ (965mm) |
| Sanding Drum RPM: | 1725 |
| Conveyor Speed: | Two Speeds 15′/49′ per min |
| Dust Port Size: | 4″ (101mm) |
| Number of Dust Ports: | 3 |
| Footprint: | 19″ x 51″ (483mm x 1300mm) |
| Width x Depth: | 56-½″ x 52″ (650mm x 1320mm) |
| Height with Dust Collection Ports: | 77-½″ (1968mm) |
| Height Without Dust Collection Ports: | 71-½″ (1816mm) |
| Conveyor Height At Lowest Setting: | 32″ (813mm) |
| Cabinet: | Steel |
| Operating Air Pressure: | 6 Bar |
| Sanding Best Oscillation: | Adjustable |
| Sanding Belt Motor Brake: | Yes. Air operated disc brake |
| CSA: | Fully Certified |
| Net Weight: | 1980 |
