Northtech NT 555 Overarm Pin Router
The Northtech NT 555-532 Overarm Pin Router sports an efficient three-phase 5 HP motor with a maximum spindle speed of 17,800 RPM. The machine comes standard with ¼”, ⅜”, and ½” collets (and matching guide pins) to accommodate a variety of tooling. Vertical spindle movement is pneumatically controlled via foot pedal and allows for custom adjustment to both initial and final plunge speed.
For current product availability and our most competitive price delivered, please contact us using the “Request A Quote” button below. Due to vendor restrictions, we cannot always advertise our highly competitive pricing online.
Features:
- 5 HP spindle
- Precision high-speed spindle bearings
- ¼”, ⅜”, and ½” collets
- ¼”, ⅜”, and ½” guide pins
- Guide fence with adjustable position
- Spindle speed of 8,900 & 17,800 RPM
- Spindle moves up and down pneumatically (3-3/8” stroke)
- Three depth-of-cut adjustments easily set with turret gauge – micro-adjustment
- Tilting table (0 – 45°)
- Pneumatic foot control of spindle
- Air-line control to adjust initial plunge speed
- Restrictor in head to adjust final plunge speed
- Blowgun and hose included for additional cleaning
- Oiler to facilitate smooth movement of the spindle
- 660 lbs. cast iron construction
- One-year parts warranty
- All machines are tested prior to shipping to ensure trouble-free start-up
Specifications:
| Motor: | 5 HP |
| Voltage: | 230/460V 3ϕ |
| Amperage: | 15/7.5 Amps |
| Spindle Speed: | 8900 / 17800 RPM |
| Control Voltage:: | 230V |
| Minimum Thickness: | 2-¾” Collet to Table |
| Maximum Thickness: | 8-½” Collet to Table |
| Vertical Travel: | 5-¾” |
| Cycle Speed: | 40 Cuts Per Minute |
| Fence Dimensions: | 2-¼” x 24” |
| Worktable Dimensions: | 18” x 24” |
| Tiltable: | 45 Degrees |
| Net Weight: | 660 lbs |
| Gross Weight: | 745 lbs |
| Machine Dimensions: | 38” x 24” x 74” |
| Packaging Dimensions: | 43” x 28” x 74” |
