Resaw Capacity: 18-3/8″
Throat Capacity: 17″
Blade Length: 158″
Minimum Blade Width: *1/16″ (*with optional Cool Blocks) or ¼″ standard
Maximum Blade Width: 1-¼″
Blade Guides:Â Laguna Guides
Upper Guide:Â Rack and Pinion
Table Size: 19″ x 25″
Table Height: 33-½″
Fence:Â Hign/Low Aluminum Standard
Overall Height: 77-½″
Base Size: 15″ x 27″
Dust Port: One 4″ Port
Motor:Â 5 HP LEESON
Volt:Â 220V. Can be ordered 1ph or 3ph
Recommended Breaker:Â 30 Amp
Weight (Net/Ship):Â 510 lbs / approx. 550 lbs
Shipping Dimensions (L x W x H): 36″ x 40″ x 89″
*Optional cool blocks required for blades less than ¼″
