Motor
- DC Brushed
- PWM (Pulse Width Modulation)
Power
- 1.5 HP
- 15 AMP
Voltage
- 110-120 volt
Frequency
- 60 Hz
Wheel Speed
- Electronic Variable 60 – 3600 RPM Forward / Reverse
Power Transfer
- Poly-groove drive belt
Machine Control
- LCD Touch Screen Smart Panel
Base Size
- 22.83″ x 16.92″
Column Diameter
- 3.15″ (80 mm)
Weight
- Net wt 304 lbs. (138 kg)
- Gross wt 326 lbs. (148 kg)
Packing Dimensions
- 72.5″ x 28.5″ x 20″
- 1840 x 725 x 406mm
Memory Settings
- 5 Memory Settings
Swing
- 20″ (1830 mm)
Spindle Taper
- MT2
Quill
- 6″ Travel – 2.6″ Diameter
Chuck Capacity
- 5/64 – 5/8″ (2 – 16 mm)
Table
- 15″ x 22″
- 3 T-slots
- 10 Clamp Holes
Table Movement
- +/- 90 Degree Tilt
- 360 Degree Swivel around column
Spindle to Table
- 30″ Max
Spindle to Base
- 49.5″ Max
Optional Accessories
- Work clamps for T-slot
- Quick clamps for Clamp Holes
- Bolt-on Work Lamps
Digital Screen Controls
| FWD / REV | Inch / mm | Speed Setting |
| Depth Setting | Material Zero | Auto Start |
| Auto Reverse | Memory Programming and Selection
|
|
*Pricing and specifications subject to change without notice
