Technical Specifications:
- Main Motor: 15 HP
- Table Size: 66 in. x 77 in.
- 4 in. thickness capacity w/ 14 in. blade
- 24-1/4 in. throat size
- 2 HP Feed Motor
- 4 feed speeds
- Return
(15 HP – 3,600 RPM Direct drive arbor motor; 14″ dia. max. saw blade cap. (9″ smallest dia.), 1-1/2″ dia. arbor; 4″ thickness capacity. 30″ Distance from saw to left edge of table. — 24-1/4″ Between saw & column, and 24″ rip distance to right of gauge. — Top roller hold-down with 7-1/2″ shortest stock handled under (1) roll, 15″ under (2) rolls.Equipped with & Features: — Overhead cutting design with single cast chain links. — Chain with automatic oil lubrication. — 2 HP Feed motor with (4) feed speeds)
