Features:
- INTELLISAND Technology: Automatically adjusts conveyor speed based on load
- Prevents gouging, damaging, or burning stock
- Provides consistent finish even with varying grain pattern and density
- Greatly increases abrasive planing and dimensioning speed
- Flatness Guarantee: Precision-flattened steel conveyor bed reinforced with four steel cross sections for no “flex” in conveyor, guaranteeing flatness to less than .010″ across the width of the sander
- Abrasive conveyor belt offers the best grip for raw wood, giving you the ability to accommodate stock that is much shorter or thinner
- Patented Abrasive Attachment System effectively tensions the abrasive wraps, preventing loose abrasive and overlap
- The easiest access to the abrasive fastening system of any drum sander! Machine design includes additional space around abrasive, eliminating the need for special tools.
- Self-cooling drum prevents overheating and extends abrasive life
Specifications:
Sanding Capacity: | Maximum Width (in): 25, 37, 50 Minimum Length (in): 3-1/2 Maximum Thickness (in): 25″ model: 6 37″ & 50″ models: 12 Minimum Thickness (in): 1/32 |
Dimensions HxWxD (in): | 25″ model: 43 x 46 x 31 37″ model: 43 x 58 x 31 50″ model: 50 x 71 x 31 |
Drum (in): (extruded aluminum) | 25″ model: 5 x 25 37″ model: 5 x 37 50″ model: 5 x 50 |
Drum speed: | 1740 RPM |
Dust Hood: (Steel hood, hinged at back) | 25” model: one (2) 4” vacuum port, min. 1000 CFM recommended 37″ & 50″ models: (3) – 4″ vacuum ports, min. 1800 CFM recommended |
Ball bearings (1”): | 4, sealed and permanently lubricated |
Conveyor Motor: | 25″ & 37″ models: 100 in. -lb. torque, direct drive D.C motor, ranged variable, 0-15 FPM 50″ model: 220 in.-lb. torque, direct drive D.C motor, ranged variable, 0-15 FPM |
Drive Motor (TEFC): | 25″ & 37″ models: 5 HP 50″ model: 7-1/2 H |
Power Requirements: | 208-230V, 60HZ; 1 Ph, 30 amp service; 3 Ph 20 amp service |
Shipping Weight (lbs): | 25″ model: 475 37″ model: 525 50″ model: 820 |
