Advanced CNC Control:
- 15” Colorful LED monitor and controller.
- AXIS CARD: 4 servo axis +1 set of analog voltage output +1 MPG handwheel axis.
- 4-axis control.
- Available to connect to various interfacing ports, including Ethernet.
- 32 Bit CPU
- Built-in open-type PLC and Macro.
Pneumatically Operated Grippers:
- The automatic feeding mechanism is equipped with 4 grippers that grip the panels and feed them to the cutting position.
- An air cylinder operates the grippers for an extremely secure gripping effect.
- The maximum gripping thickness is 150 mm.
Finished Product Outfeed Plate:
- The outfeed plate, actuated by an air cylinder, automatically tilts downward to outfeed the finished products after cutting.
Programmable Band Blade Swiveling +-90 Degrees:
- The band blade can swivel to various angular positions through the computer control. Swiveling angles include +-90 Degrees.
- This, combined with the X- and Y-axis travels on the automatic feeding mechanism, allows for cutting any complicated curve.
Specifications:
- Main Motor Hp. = 15 hp.
- Voltage/ Freq. = 230 Volt 60Hz
- Phase = 3 Phase
- Total Hp. = 21.4 Hp.
- Electronics = CE Approved Components
- Touch Screen = 15” LED Monitor
- Operator Panel = Mobile Cabinet
- Max. Length = 98.42”
- Max. Width = 47.24”
- Max. Thickness = 5.90”
- Able Cut Angle = +90 / -90 Degrees
- Arbor Rpm = 750 RPM
- Blade Size = 5900 x 12.7 x 0.8mm
- Blade Speed = 6550 FPM
- Dust Collection = (2) 4” @ 900 CFM
- Emergency Stop = Push Button
- Blade Wheel Dim = 35”
- Net Weight = 6614 Lbs.
- Gross Weight = 7717 Lbs.
- Machine Dims. = 166 x 130 x 103 In.
